Simple serialization format for logging and analytics in Go

I was looking to save multiple records with somewhat flexible schema to a file. Go has plenty of options but I couldn’t find anything that was just right.

My desired features were:

human-readable so that I can use tools like grep or tail to look at the file
records are not fixed i.e. can have variable number of fields
no need to support nested records
allows for simple and efficient implementation

Here are some most popular available options and why they don’t exactly fit the bill:

csv - efficient but uses fixed records; not very readable if there are many fields on a single line
json - not very readable
protocol buffers - binary so unreadable; needs up-front scheme

I designed and implemented my own format in package siser (which stands for Simple Serialization).

You’ll not be surprised by how it looks:

url: http://blog.kowalczyk.info/index.html
code: 200
large field:+13789
this is large data, 13789 bytes in size...
---

It’s a typical key/value serialization with one neat feature: support for large data (e.g. an image or long text).

The format is line oriented. Each line is ${key}: ${value}\n.

If the value is larger than 120 bytes or is not ascii text (with bytes outside of 32-127 range), I serialize it as large value:

${key}:+${value_length}\n
${value}\n

To separate records I use ---\n.

I use this format for 2 main purposes:

structured logging to help in debugging
logging events for analytics

Using the library

When used for analytics, each record represents an event. I save the events to a file and later on process the whole file record-by-record and calculate desired statistics.

Here’s how we would log info about HTTP requests:

func logHTTPRequest(w io.Writer, url string, ipAddr string, statusCode int) error {
    var r siser.Record
    // you can append multiple key/value pairs at once
    r.Append("url", url, "ipaddr", ipAddr)
    // or assemble with multiple calls
    r.Append("code", strconv.Itoa(statusCode))
    /// ... more fields
    d := r.Marshal()
    _, err := w.Write(d)
    return err
}

Here’s a full example of logging HTTP requests.

Let’s say we wrote the data to http_access.log file. Here’s how we would process the records:

f, err := os.Open("http_access.log")
panicIfErr(err)
defer f.Close()
r := siser.NewReader(f)
for r.ReadNext() {
    _, record := r.Record()
    code, ok := r.Get("code")
    // get rest of values and do something with them
}
panicIfErr(r.Err())

Here’s a full example of calculating basic daily statistics on HTTP requests (most frequently visited pages, most frequent 404s, most frequent referrers).

Annoyances

The library doesn’t offer marshaling directly to/from structs. Could be added with a bit of reflection.

It doesn’t directly support non-string types like int or time.Time. You have to convert them to/from string yourself.

Implementation notes

Some implementation decisions were made with performance in mind.

Given key/value nature of the record, an easy choice would be to use map[string]string as argument to encode/decode functions.

However []string is more efficient than a map. A slice can be reused across multiple records. We can clear by re-slicing as empty slice and reusing underlying array. A map would require allocating a new instance for each record, which would create a lot of work for garbage collector.

When serializing, you need to use Reset method to get the benefit of efficient re-use of the record.

When reading and deserializing records, siser.Reader uses this optimization internally.

The format avoids the need for escaping keys and values, which helps in making encoding/decoding fast.

How does that play out in real life? I wrote a benchmark comparing siser vs. json.Marshal. It’s roughly similar when writing but about 8x faster when reading.

$ go test -bench=.
BenchmarkSiserMarshalWriteMany-12        1329409               871.1 ns/op
BenchmarkSiserMarshalWriteSingle-12      1000000              1088 ns/op
BenchmarkJSONMarshal-12                  1340370               767.9 ns/op

BenchmarkSiserUnmarshal-12               4720020               251.5 ns/op
BenchmarkJSONUnmarshal-12                 603591              2036 ns/op

The format is binary-safe and works for serializing large values e.g. you can serialize png image

It’s also very easy to implement in any language.
